Wallbox EV Charger OCCP APP Fast EV Charger Manufacturer Electric Car Charging Stations 30kW

Specification

Model:    182kW DC Fast Charger-Triple Ports

Input Electrical

Input Voltage

AC400v±10%

Input Frequency

50Hz

Power factor

0.99 at nominal output

Efficiency

≥95%

Output Electrical

DC output single charging

CCS2: 160kW max

CHAdeMO: 60kW max

DC output simultaneous charging

CCS2: 80kW max, CCS2: 80kW max, AC-Type2: 22kW max or

CCS2: 100kW max, CHAdeMO: 60kW max, AC-Type2: 22kW max

DC output voltage charging

CCS2: 200-1000VDC

CHAdeMO: 200-500VDC

DC output current charging

CCS2: 0-200A

CHAdeMO: 0-125A

Structure

Net Weight

370kg

Dimension (H x W x D)

1880 x 580 x 750mm

Application Scenarios

All Kinds of Electric Vehicles

Cabinet Materials

Metal body

Connectors

CCS2, CHAdeMO, AC-Type2

Installation Method

Floor-mounted

Cable Length

5m (Length customizable)

Environment

Working
Temperature

-30℃~+55℃

Working Humidity

5%~95% non-condensable

Height Above Sea Level

2000m

IP Grade

IP55

Cooling Method

Air Cooling

Noise Control
